Condition Monitoring

Wireless vibration measurement in industry and traffic

Energy self-sufficient TELID®TAGs clearly identify objects
and register their vibrations.

RFID Vibration Sensor Transponder TELID®281

The new sensor transponder TELID®281.3Dm measures vibrations in a frequency range from 0 to 1.6 kHz with an acceleration resolution of better than 5 mg. Its integrated processor performs signal integrations as required and, in the future, simple Fourier transformations. All calibration data and essential maintenance data remain stored on the permanently installed TELID sensor.

RFID Communicator iLD®POCKETwork

With the wireless mobile communication device POCKET®work you can reach every position on your object to be inspected. The results are transmitted to a mobile device via Bluetooth.

Your advantage:
Clear, forgery-proof and permanently marked objects, exactly reproducible measurement through unchanged and contactless measurement coupling as well as the simplest communication technology.

Convenient maintenance and servicing processes using mobile RFID technology

Intelligent maintenance processes require intelligent and easy-to-handle sensors. In the age of the Internet of Things, simple and standardized communication interfaces are essential.

Smart mobile data acquisition via RFID is the solution.

Condition monitoring on machines and drive components

Using stationary RFID technology, you can register vibrations on moving parts in machines, gears or conveyor systems without contact. microsensys develops and produces your suitable miniaturized and integrable RFID reader.



Download datasheet

RFID Technology:
13.56 MHz, ISO 14443

Chip Types:
iID-L

Communication Distance:
0 ... 20 mm

Memory:
128 bit EEPROM free memory

Sensor:
MEMS sensor, 3D acceleration (x, y,z-axis)

Range:
0 g ... +/-2 g, +/-4 g, +/- 8 g

Resolution:
8 bit

Measure Mode:
GET VALUE, on line measurement

Storage Temperature:
-35°C ... +125°C

Packaging:

  • epoxy glass fiber enforced (black),
  • half lens housing

Size:
approx. D 15 mm, max. TH 3.0 mm

Special Features:

  • passive vibration sensor device
  • very useful for wireless sensor communication
  • industry solutions and maintenance
  • for quick quality checks
TELID®281.3D - RFID vibration 3D sensor transponder
by microsensys
passive vibration sensor device
very useful for wireless sensor communication
industry solutions and maintenance
for quick quality checks

Download datasheet

RFID Technology:
868 MHz, ISO 18000-6 Type 3, EPC C1 G2

Antenna:
PA3 or CA1015, depending on type

Communication Distance:
0 ... 80 cm

HOST Interface:
Bluetooth class 2 and USB 2.0

Operation Mode:
SLEEP, ACTIVE, SCAN

Communication Mode:
SPC or DOC

Memory:

  • 2 MB Flash for data capture memory
  • 16 kbit EEPROM for configuration

Packing:
Plastic

Size:
small POCKET case, approx. 86 x 54 x 10 mm³

Special Features:

  • POCKET reader for mobile solutions
  • with three programmable buttons
  • OLED 96 x 64 matrix display
  • real time clock set up by HOST
  • integrated memory
  • buzzer with variable frequencies
  • for mobile RFID data capture
Reader: POCKETwork UHF
by microsensys
POCKET reader for mobile solutions
with three programmable buttons
OLED 96 x 64 matrix display
real time clock set up by HOST

Download datasheet

RFID Technology:
13.56 MHz, ISO 15693, ISO 14443

Antenna:
K5 or P1333, depending on type

Communication Distance:
0 ... 50 mm

HOST Interface:
Bluetooth class 2 and USB 2.0

Operation Mode:
SLEEP, ACTIVE, SCAN

Communication Mode:
SPC or DOC

Memory:

  • 2 MB Flash for data capture memory
  • 16 kbit EEPROM for configuration

Packing:
Plastic

Size:
small POCKET case, approx. 86 x 54 x 10 mm³

Special Features:

  • POCKET reader for mobile solutions
  • with three programmable buttons
  • OLED 96 x 64 matrix display
  • real time clock set up by HOST
  • integrated memory
  • buzzer with variable frequencies
  • for mobile RFID data capture
Reader: POCKETwork HF
by microsensys
POCKET reader for mobile solutions
with three programmable buttons
OLED 96 x 64 matrix display
real time clock set up by HOST
